Portable LCD Tester for Li-PO Batteries - ACM

Precise Real-Time Diagnostics:
Don't guess if your battery still has enough power for a game! By connecting the balancing connector to this ACM Tester, the LCD display will automatically cycle through the values: first it will show you the total voltage (e.g. "ALL 11.4"), then it will read cell 1 ("No.1 3.80"), then cell 2 ("No.2 3.80") and so on. This is vital to understand not only if the battery is charged, but if the cells are balanced correctly with each other (if one cell is drastically lower than the others, the battery is damaged).

Programmable Audible Alarm (Dual Buzzer):
On the top, enclosed in the transparent sheath, there is a small button. By pressing it, you will enter the programming mode of the powerful dual audible alarm. Unlike standard fixed buzzers, here you can set the emergency threshold (from 2.7V up to 3.8V). When you leave it connected to the battery during the game, and a single cell drops below the value you have chosen, the tester will make its two speakers whistle deafeningly, saving your LiPo from chemical death!

Main Advantages

• Integrated LCD Display: Clearly read the total and individual cell Volts.
• Adjustable Alarm: Set the guard limit yourself before the dual buzzer goes off.
• Multi-Chemistry: Reads Li-Po, Li-Ion, Li-Fe and Li-Mn batteries (from 1S up to 8S).
• Dual Function: Use it at home to check the state of charge, or in the rifle as a life-saving alarm during the game.

Technical Specifications

• Manufacturer: ACM
• Type: Capacity Tester / Voltage Alarm LCD
• Supported Batteries: 1-8S (Li-Po / Li-Ion / Li-Mn / Li-Fe)
• Test Accuracy: +- 0.01V
• Unit Voltage Range: 0.5V ~ 4.5V
• Total Voltage Range: 3.7V ~ 30V
• Low Voltage Alarm: Programmable (Adjustable threshold from 2.7V to 3.8V, or deactivatable - OFF)
• Dimensions: 40mm x 24mm x 13mm

Package Contents

• 1x Portable LCD Battery Tester - ACM
